Essential Lab Lattice Frame Foot – Brushed Aluminum & Stainless Steel
Product Overview
The lab lattice frame foot—also referred to as the lab frame base clamp, support rod base, lattice foot, or bench mount clamp—provides solid anchoring for rock‑solid stability in laboratory lattice frameworks. Engineered for permanent mounting to laboratory bench tops, floors, or walls, this base securely accommodates standard 1/2″ (13mm) and 12mm diameter lab rods, delivering a rigid, wobble‑free foundation for complex distillation setups, reactor frames, and heavy glassware assemblies.
Available in brushed aluminum or premium stainless steel, these feet offer exceptional durability and resistance against harsh laboratory chemicals, frequent sanitization, and wear. Whether you are building a fume hood grid, a floor‑to‑ceiling pilot rig, or a custom benchtop frame, EduSupports has the right base for your application.
Key Features
Permanent versatile mounting – easily mounts horizontally or vertically to lab benches, walls, or floors to eliminate frame sway
Precision fit for 12mm–13mm rods – perfectly compatible with standard 1/2″ (13mm) and 12mm lab support rods
Two premium material options – brushed aluminum (lightweight, cost‑effective, sleek modern finish) or stainless steel (maximum chemical resistance, ideal for cleanrooms and aggressive environments)
Ready for installation – each lab frame foot is supplied with three heavy‑duty mounting screws, saving time and sourcing hassle
Thickened flange design – three‑point screw configuration ensures even load distribution, preventing tipping even when holding heavy overhead stirrers or large separatory funnels
Zero‑tolerance precision bore – machined to tight tolerances for a snug fit; integrated locking set screw provides a powerful grip without scoring or damaging lab rods
Why Choose Our Lab Frame Foot Clamps?
The lab lattice frame foot offers several distinct advantages for laboratory framework construction.
First, it is engineered for lab safety. When building a lab lattice network, the base dictates the structural integrity. Our frame feet feature a thickened flange design with a three‑point screw configuration, ensuring even load distribution and completely preventing tipping risks even when holding heavy overhead stirrers or large separatory funnels.
Second, the zero‑tolerance precision bore ensures a snug fit for 12mm to 13mm rods. The integrated locking set screw provides a powerful grip without scoring or damaging your lab rods.
Third, these bases offer cross‑industry durability. Whether deployed in university chemistry labs, R&D cleanrooms, or industrial petrochemical testing stations, they withstand daily exposure to acid fumes, solvents, and rigorous cleaning protocols.
| Feature | Brushed Aluminum | Stainless Steel |
|---|---|---|
| Weight | Lightweight | Heavier |
| Cost | Cost‑effective | Premium |
| Chemical resistance | Good | Maximum |
| Corrosion protection | Moderate | Excellent |
| Best for | Standard physical/organic chemistry setups | Cleanrooms, high‑humidity, acid‑heavy environments |
Specifications – Find Your Perfect Model
SKU | Material | Rod Compatibility | Finish |
0207010150-21 | Zinc alloy electroplated | Φ12–13mm | Electroplated |
0207010150-22 | Aluminum alloy | Φ12–14mm | Brushed |
Common Specifications
| Specification | Detail |
|---|---|
| Product name | Lab Lattice Frame Foot / Lab Frame Base Clamp |
| Rod accommodation | Φ12mm – 13mm (1/2″ lab support rods) for zinc alloy; Φ12–14mm for aluminum alloy |
| Material options | Zinc alloy electroplated / Aluminum alloy |
| Mounting type | 3‑hole surface mount (supplied with 3 screws) |
| Application | Fume hood grid setup, distillation frame mounting, pilot plant rigging |
Applications – Where to Use Lab Frame Feet
| Environment | Typical Use |
|---|---|
| Fume Hood Lattice Setup | Permanently mount to interior walls of fume hoods for efficient, space‑saving vertical arrays |
| Floor‑to‑Ceiling Lab Frames | Acts as robust floor shoes to support pilot‑scale reactors and larger equipment |
| Benchtop Rigging | Secures custom grids for automated dosing systems, sensors, and optical components |
| University Chemistry Labs | General framework support for student and research setups |
| R&D Cleanrooms | Corrosion‑resistant mounting for sensitive environments |
| Industrial Petrochemical Testing | Withstands acid fumes, solvents, and harsh conditions |
Tips for Optimal Performance
For fume hood installations, mount vertically on interior walls to maximize workspace
For floor mounts, ensure the surface is level before securing
For heavy overhead loads, use all three mounting screws and verify tightness periodically
Select stainless steel for high‑humidity, cleanroom, or acid‑heavy environments; choose aluminum for standard physical or organic chemistry setups
Why Choose EduSupports?
EduSupports delivers quality laboratory hardware designed for education, research, and industrial budgets. Our lab lattice frame feet feature:
Precision‑engineered bore – zero‑tolerance fit for 12–13mm rods
Thickened flange with three‑point mounting – even load distribution, no tipping
Two material options – zinc alloy electroplated or aluminum alloy
Complete hardware included – three mounting screws with every unit
Cross‑industry durability – withstands chemicals, solvents, and frequent cleaning
Competitive pricing – professional quality at accessible prices
Each EduSupports lab frame foot is manufactured to high standards, trusted by universities, research institutes, and industrial laboratories worldwide.
